About the Sinclair ZX81

For the uninitiated the ZX81 was a small 8-bit home microcomputer invented and produced by Sinclair Research Limited of Cambridge, England. Sinclair Computers (renamed Sinclair Research Ltd. in March 1981) was founded by Sir Clive Sinclair, inventor of the pocket television, the first pocket calculator, the famous rubber-keyed Sinclair ZX Spectrum and later the not-so-popular Sinclair C5 electric car. Fans of this small humble home microcomputer (and there are many of them) will quite rightly tell you that this machine kick-started the home computing boom of the early eighties, mainly due to its low price and user friendly attributes.

As its name might suggest, this machine entered the then fledgling home computer market in 1981 as a home-build kit priced at £49.95 and a ready built option at £69.95, following on from the already successful ZX80 (original price £99.95) released in 1979. Sinclair Research managed to keep the price of the Sinclair ZX81 so low by reducing the number of chips on the motherboard from 21 on the ZX80 to 4 on the ZX81. The computer was sold via its traditional method of mail-order (over 300,000 were sold this way by the end of January 1982) and also via the high street with the involvement of W.H. Smith, a British chain of newsagents and stationers. Sales of the ZX81 were huge and by February 1982 Sinclair was producing over 40,000 units per month and still could not keep up with demand. Over a million units were produced within two years of launch.

Sinclair Research teamed up with Timex in the US to produce the Timex Sinclair 1000, a version of the ZX81 for the North American home computer market, which sold in considerable numbers and was manufactured by Timex in Dundee, Scotland.

K cursor

Sinclair ZX81 Specifications

Sinclair ZX81 circuit boardThe ZX81 used a completely re-designed main board with a much reduced chip-set (from 24 chips on the ZX80 to 4 on the ZX81) mainly due to a new CPU which replaced 18 chips on the ZX80 main board. The ZX81 had no sound chip or speaker and had monochrome output to a UHF TV set via an RF Modulator. Data was transferred to/from the ZX81 via 3.5mm jacks and a normal audio cassette player. Power input was from a custom Sinclair 9V DC transformer.

Depth

167 mm (6.32 in)

Height

40 mm (1.57 in)

Weight

350 grams (12.15 oz)

CPU

Z80z at 3.25 MHz

Display

24 lines x 32 characters (text), 64 x 44 pixels graphics mode

ROM

8K with BASIC interpreter

RAM

1K internal, externally expandable to 16K

Power

420ma at 7-11V DC

K cursor

Software for the ZX81

A large amount of software was produced for the Sinclair ZX81, ranging from home business software to the games we wasted our youth on! It was the time of the bedroom-coder, a new breed of computer programmer who produced software from home and either marketed and produced the finished article themselves in small scale operations, or sold the code to a larger software publishing house for a one-off payment or royalties. It would be impossible (at least too time consuming) to list all of the software ever produced by every individual and software house here on this site, instead I have elected to choose some of the biggest software houses of the time and list their most popular titles. The titles in each software viewer are by no means exhaustive. More titles will be added as they become part of my own collection. You can purchase original software for the ZX81 and ZX Spectrum from Retrogear UK - Sinclair ZX80, ZX81 ZX Spectrum and QL specialists



Sinclair software viewer

Sinclair Branded Software

Sinclair Research teamed up with several software houses to produce their own-brand software for the Sinclair ZX81. The most prolific of these was to be Psion and ICL (International Computers Limited), with a small range of business, educational and entertainments titles following. Also worth mentioning is the Sinclair Learning Lab see the Sinlair Learning Lab and a small range of multi-title software cassettes released by Sinclair with black and red inlays matching the packaging style of the Sinclair ZX81 itself.
Open Viewer open viewer

J. K. Greye software viewer

J. K. Greye Software

Responsible for possibly the most famous Sinclair ZX81 game of all time - 3D Monster Maze, one of the first games on a home micro to be in first person perspective. This title followed on from the successes of their previous multi-title releases and Catacombs, a multi level graphical adventure. They later became New Generation Software and sported a new full colour look open viewer to their inlay graphics.
Open Viewer open viewer

Quicksilva software viewer

Quicksilva

Some of the best looking inlays were to be found on Quicksilva games, and luckily the games themselves were some of the greatest arcade game ports you could find on the Sinclair ZX81. QS Asteroids, QS Defenda, Galaxians, and QS Invaders were amongst these titles which were supplied unusually with a set of memory addresses that you could 'POKE' see example here see POKE card so that the game could be modified to your liking!
Open Viewer open viewer

Software Farm software viewer

Software Farm

OK, so not necessarily a big software house but regarded by many as one of the best for finally producing what all Sinclair ZX81 fans had dreamed of - high resolution software. The end result was Sinclair ZX81 software that ran at the same resolution as its replacement, the Sinclair ZX Spectrum.
Open Viewer open viewer

K cursor

Peripherals for the Sinclair ZX81

To be added soon...

K cursor





Sinclair ZX81 Emulation

To be added soon...

K cursor





A selection of images

To be added soon...
